SIMATIC DP Connection Module IM 153 1 for ET 200M, 6ES7153 1AA03 0XB0

? Product Name

SIMATIC DP Connection Module IM 153‑1 for ET 200M (Spare Part)

? General Description

The 6ES7153‑1AA03‑0XB0 is a PROFIBUS‑DP slave interface module used to connect up to 8 ET 200M I/O modules to an S7‑300 system via a PROFIBUS DP network. Designed for distributed automation, it supports hot-swapping and fail-safe modules, and allows integration of signal modules with extended user data like HART

⚙️ Key Features

• Interfaces:
• PROFIBUS DP slave (RS‑485, up to 12 Mbps)
• 9-pin Sub‑D PROFIBUS connector with auto baud‑rate detection
• Installation: DIN‑rail; IP20 protection
• Scope: Connects a maximum of 8 ET 200M modules to the bus
• Hot‑swap capable: Modules can be removed or inserted without powering down
• Supports:
• PROFIsafe (fail‑safe modules)
• Modules with expanded user data (e.g. HART)

? Technical Specifications

• Power supply: 24 V DC, bus backplane +5 V (max. 1 A)
• Current draw: max. 350 mA @24 V DC; inrush current ~2.5 A
• Power loss: approx. 3 W
• Data size: 128 bytes of inputs and 128 bytes of outputs
• Isolation voltage: 500 V
• Temperature: 0 °C to +60 °C (operating)
• Dimensions: approx. 13.1 × 15.2 × 5.2 cm; weight ~0.27 kg

? Typical Applications

• Provides a PROFIBUS DP interface for ET 200M distributed I/O systems
• Ideal for automation environments using S7‑300 controllers
• Facilitates modular and scalable I/O configurations, including safety and smart field‑device integration

⏳ Lifecycle & Note

• Classified as a spare part—originally phased out (product cancellation effective Oct 1, 2024)
• RoHS‑compliant; contains trace lead, compliant under REACH
